Electrically Tunable Metasurface in TN LC Configuration with Enhanced Quality Factor and Metaatom-Induced Alignment



Dynamic metasurface with subwavelength dimensions has emerged as a key optical technology in recent years. Although various active tuning mechanisms are being proposed, liquid crystal-based dynamic metasurface remains attractive due to its large index variation, electrical tunability, reliability, and mass fabricability. In this work, we report a dynamic metasurface for amplitude modulation in reflection, with twisted nematic liquid crystal configuration to reduce broadband reflection in the off state. The metasurface consists of coupled subwavelength grating fingers, which provide alignment for the liquid crystal without the need for an additional alignment material or process. The alignment of liquid crystal materials was examined between crossed polarizers, and the twist of nematic liquid crystal was confirmed. The coupled grating fingers exhibit a resonance quality factor of 27 at telecommunication wavelength and an amplitude modulation depth of 8 times of the minimum at 1630 nm. This work highlights the potential of liquid crystal-based tunable metasurface, combining polarization control via liquid crystal and spectrum control via metasurface. Furthermore, it also shows a way in which the interaction between liquid crystal and metasurface is used for an alignment layer-free cell assembly process.













You can access the full article here: https://doi.org/10.1364/OL.537839
